Size 3 Budget Door Closer with Arm and Body Including PA Bracket

A Size 3 Overhead Door Closer is the industry standard for medium-duty commercial and residential doors. In the hierarchy of architectural hardware, “Size 3” refers to the specific closing power of the internal spring, engineered to handle doors with a width of up to 950mm and a weight of up to 60kg.

It is the most common closer size used in the UK and Europe, providing the necessary force to ensure that fire doors close reliably without being so heavy that they impede accessibility.

A Size 3 Overhead Door Closer is the industry standard for medium-duty commercial and residential doors. In the hierarchy of architectural hardware, “Size 3” refers to the specific closing power of the internal spring, engineered to handle doors with a width of up to 950mm and a weight of up to 60kg.

It is the most common closer size used in the UK and Europe, providing the necessary force to ensure that fire doors close reliably without being so heavy that they impede accessibility.

Performance & Fire Safety Compliance

The Size 3 Overhead Door closer is a critical component for building safety, specifically designed to meet stringent fire and accessibility regulations.

• Fire Door Integrity: Size 3 closers are typically certified for FD30 and FD60 fire doors. Their primary function is to ensure that a fire door returns to a fully closed and latched position after every use, maintaining the building’s fire compartments.

• Dual Valve Speed Control: These units feature two independent adjustment valves:

  • Sweep Speed: Controls the closing velocity from the fully open position to the final 15 degrees.

  • Latch Speed: Controls the final “snap” of the door to ensure it overcomes the latch bolt and weather stripping.

• Aluminum Construction: Usually housed in a high-quality cast aluminum body with a steel scissor arm, providing a balance of lightweight design and heavy-duty durability.

• Non-Handed Design: These closers are universal, meaning they can be fitted to either left-hand or right-hand doors without modification.

Primary Applications of Size 3 Overhead Door Closer

Because of its balanced power-to-resistance ratio, the Size 3 Overhead Door Closer is the preferred choice for:

1. Apartment Entrance Doors: Ensures the entrance to a flat self-closes to prevent the spread of smoke into communal corridors.

2. Office Corridors: Provides a quiet, controlled close that prevents doors from slamming in professional environments.

3. Standard Timber Fire Doors: Specifically calibrated for the weight and hinge friction of standard 44mm and 54mm thick timber fire doors.

4. Healthcare Facilities: Offers enough power to close doors reliably while maintaining the “opening force” requirements for accessibility.

Installation Pro-Tip: Overcoming “Latch Bounce”

The most common issue with door closers is a door that stops just short of the frame or “bounces” off the latch.

1. The 90-Degree Rule: For the most efficient closing power, ensure the arm is set at exactly a 90-degree angle to the door frame when the door is closed.

2. Micro-Adjustments: When adjusting the speed valves, only turn them by 1/8th of a turn at a time. The hydraulic system is highly sensitive; a half-turn can be the difference between a slow glide and a dangerous slam.

3. Check the Hinges First: A door closer is not designed to fix a dragging door. Ensure your hinges are well-lubricated and the door is properly aligned before mounting the closer.

4. Weather Strip Resistance: If you have thick smoke seals or weather stripping, you may need to increase the Latch Speed slightly to give the door the final “push” it needs to compress the seals and click into the strike plate.

This Size 3 Overhead Door Closer with arm and body is a practical and cost-effective solution for smooth and controlled door closing. Supplied complete with a PA bracket, it offers easy installation and reliable performance for both internal and external doors. Constructed from durable materials, this door closer ensures long-lasting use, making it an ideal choice for residential, commercial, and light industrial applications.

Designed for everyday functionality, the Size 3 Overhead Door Closer provides effective control over door movement, helping to reduce noise, prevent slamming, and protect door frames. Simple to fit and adjust, it delivers dependable performance at an affordable price. Whether used for refurbishments, replacements, or new installations, this Size 3 Overhead Door Closer  combines practicality, durability, and value in one solution.
