Name: 2 Piece Din Euro Sashlock 72mm Centres Backset 60mm Radius Edge Mortice Door Lock
Brand: Vier
SKU: ZO-VDL7260-R-SSS
Availability: InStock

Elevate your door security and aesthetics with this 2 piece din euro sashlock designed to meet the highest standards of durability and precision. Featuring a radius edge mortice door lock design with 72 mm centres euro sashlock configuration and a 60mm backset euro sashlock, this mortice lock brings professional-grade reliability to commercial and residential doors alike.

Overview of the 2 Piece Din Euro Sashlock 72mm

This din euro sashlock 72mm model includes two essential components—a latch and a deadbolt—that function independently for ease of use and enhanced security. The lock’s compact design with a 60mm backset euro sashlock offers compatibility with a wide range of doors while ensuring timeless security.

The radius edge mortice door lock adds an elegant touch with its smoothly rounded faceplate, making installation seamless and visually pleasing with minimal interference to door edges.

Key Features & Specifications

Feature	Description	Benefit
Lock Type	2 piece DIN Euro sashlock	Combines latch and deadbolt in one system
Centres (c/c)	72mm centres euro sashlock	Matches standard spindle distance
Backset	60 mm backset euro sashlock	Suitable for various door thicknesses
Edge Style	Radius edge mortice door lock	Smooth rounded edges reduce wear and improve fit
Material	High-grade steel with satin stainless finish	Corrosion resistance & durable performance
Lock Function	Separate latch and deadbolt operated via handle and euro cylinder	Convenience and added security
Certification & Standards	BS EN 12209 Grade 3, fire-rated FD30/FD60 potential	Compliance with building and fire safety regulations

Detailed Specifications

Parameter	Measurement/Description
Case Size	150mm x 85mm
Backset (Distance to Keyhole)	60mm
Spindle to Euro Centres	72mm
Bolt Throw	20mm (deadbolt fully extends for secured locking)
Faceplate Style	Radius Edge Mortice
Finish	Satin Stainless Steel (also available in polished or PVD finishes)
Locking Mechanism	Euro profile cylinder operated latch and deadbolt

How the 2 Piece Din Euro Sashlock Works

The 2 piece din euro sashlock offers distinct operation for the latch and the deadbolt:

The latch is spring-loaded and retracts by turning the lever handle, allowing the door to open easily. Once released, it springs back to keep the door closed.
The deadbolt provides additional security by extending fully when the euro cylinder is locked, offering resistance against forced entry.
The 72mm centres euro sashlock ensures seamless compatibility with euro profile handles, commonly used in commercial-grade doors.

Comparison Table: DIN Euro Sashlock Models

Feature	2 Piece DIN Euro Sashlock 72mm Centres 60mm Backset	Standard Single-Unit Euro Sashlock
Lock Type	Separate latch and deadbolt (2 piece)	Combined latch/deadbolt unit
Centres (c/c)	72mm centres euro sashlock	Varies, often 45mm or 60mm
Backset	60mm backset euro sashlock	Varies, typically less precision on radius edges
Edge Style	Radius edge mortice door lock	Usually square or less refined edges
Security	Higher security with dual locking mechanisms	Moderate security
Suitable For	Commercial and public buildings	Residential or light commercial

This distinction makes the 2 piece din euro sashlock the preferred choice for professional installations where robust security and aesthetic detailing are paramount.

Advantages of Radius Edge Mortice Door Lock

The radius edge mortice door lock design reduces surface wear on the door and door frame caused by sharp edges, extending door life.
Rounded edges provide a clean, flush finish that enhances overall door appearance.
This design also eases the lock installation process by better accommodating slight variations in door edge thickness.

Installation Insights 🛠️

Installing the 60 mm backset euro sashlock requires precision but is straightforward with proper tools:

Mark mortice positions based on diagram specifications for 72mm centres and 60mm backset.
Cut the mortice into the door edge carefully, matching the radius edge profile for a snug fit.
Install the latch and deadbolt components separately, ensuring proper alignment.
Secure the faceplate flush with the door edge using provided screws.
Attach compatible euro profile handles and lock cylinders (sold separately) for full functionality.

Frequently Asked Questions (FAQs) ❓

Q1: What sizes of euro profile cylinders does this lock fit?
This lock fits standard euro profile cylinders compatible with the 72 mm centres euro sashlock setup.

Q2: Can the latch be reversed?
Yes, the latch is reversible on-site, allowing for both left and right-handed door orientations.

Q3: Is this lock suitable for fire doors?
Yes, when used with appropriate intumescent seals, this lock meets fire safety standards for FD30 and FD60 doors.

Q4: Does the satin stainless steel finish resist corrosion?
The finish is designed for durability and corrosion resistance, ideal for both interior and exterior doors.

Q5: Can this lock be used on wooden and metal doors?
Yes, it is compatible with timber and metal doors, making it widely versatile.

Key Benefits Summary 📌

Benefit	Why It Matters
Dual Locking Mechanism	Enhanced security with separate latch & deadbolt
Radius Edge Design	Smooth edges improve durability and aesthetics
Precise 72mm Centres	Compatible with industry-standard handles
Suitable 60mm Backset	Fits most door thicknesses and ensures smooth operation
Fire Rated & CE/UKCA Marked	Meets compliance for commercial and public buildings

Final Thoughts: A Robust, Elegant Euro Profile Mortice Lock

The 2 piece din euro sashlock 72mm centres backset 60mm radius edge mortice door lock stands out as a top-tier choice for anyone seeking commercial-grade security combined with refined aesthetics. Its dual mechanism offers usability and safety, while the radius edge and satin stainless finish deliver elegance and durability. Perfect for offices, public spaces, and residential projects requiring reliable locking hardware.

Choose this model for peace of mind, excellent compatibility, and long-lasting performance. Upgrade your doors today with this precision-engineered 72mm centres euro sashlock trusted by professionals worldwide.
