The 50mm Glass Ball Mortice Knob is a sophisticated architectural detail that combines the classic charm of a “crystal” sphere with modern mechanical reliability. Perfectly sized at a 50mm diameter, this knob is engineered to provide a comfortable, ergonomic grip for standard internal doors while acting as a striking “light-catcher” in hallways and living spaces.
Crafted from high-clarity, flame-polished glass and mounted on a durable metal rose, this mortice knob is designed for use with internal latches and locks, offering a weighted, premium feel that synthetic alternatives cannot replicate.
A 50mm Glass Ball Mortice Knob is a technical balance between aesthetic transparency and structural strength. Unlike acrylic knobs, high-quality glass remains clear for decades without yellowing or scratching.
-
High-Clarity Optical Glass: Each 50mm sphere is crafted from lead-free, toughened glass. The flame-polishing process removes internal inclusions, ensuring the knob remains “crystal clear” even when exposed to direct UV sunlight in bright coastal or garden-facing rooms.
-
Ergonomic 50mm Diameter: The 50mm size is the industry standard for “palm-fit” comfort. 50mm Glass Ball Mortice Knob provides enough surface area for a secure grip to operate heavy timber doors, yet maintains a delicate, minimalist profile that doesn’t overwhelm smaller rooms.
-
Precision Metal Rose Bases: The glass ball is permanently bonded to a reinforced metal rose. Available in finishes like Polished Chrome, Satin Nickel, or Antique Brass, these bases allow the hardware to match the existing hinges and décor themes throughout a property.
-
High-Torque Grub Screw Fixing: To prevent the common issue of knobs “spinning” on the spindle, these sets feature a hardened grub screw that bites into the 8mm steel spindle, ensuring a permanent, wobble-free connection.
Technical Specifications of 50mm Glass Ball Mortice Knob
| Feature | Detailed Specification |
| Knob Diameter | 50mm (Spherical) |
| Projection | 75mm – 80mm from the door face |
| Rose Diameter | 55mm – 60mm (Concealed or Visible Fixings) |
| Spindle Size | 8mm x 8mm (Universal UK/EU Standard) |
| Material | Toughened Glass + Solid Brass or Zinc Alloy Rose |
| Mechanism | Available in Sprung or Unsprung (Latched) |
| Compatibility | Internal Doors (35mm – 44mm Thickness) |
Recommended Hardware Pairings
To ensure a “luxury” operation, the internal mechanics are just as important as the glass knob itself:
-
Heavy-Sprung Mortice Latch: Most glass knobs are unsprung. You must use a “heavy-sprung” latch (usually 3″ or 4″ in length) to ensure the knob returns to its neutral position and doesn’t feel “loose” or “rattly.”
-
Extended Backset Latch: Because a 50mm sphere projects further than a flat lever, use a 76mm (3″) or 100mm (4″) latch. This moves the knob further away from the door frame, preventing “knuckle-clash” when you turn the glass.
-
Ball-Bearing Hinges: Pair these knobs with high-quality hinges in a matching finish (e.g., Polished Chrome) to ensure the door swings silently and smoothly, complementing the high-end feel of the glass.
Installation Pro-Tip: The “Grub-Screw Lock”
To ensure your glass knobs stay secure for years:
-
Insert the spindle so it sits equally inside both knobs (at least 15mm deep on each side).
-
Tighten the rose screws into the door face first.
-
The Secret Step: Once the knobs are in place, tighten the grub screw onto the “V” groove or flat side of the spindle.
-
For extra security in high-traffic homes, a tiny drop of thread-locking fluid on the grub screw will prevent it from vibrating loose over time, keeping the glass ball perfectly rigid.
Bring classic elegance to your doors with this plain 50mm Glass Ball Mortice Knob , designed with a 50mm diameter for a comfortable and stylish grip. The smooth glass finish provides a refined and timeless appearance that complements a wide range of interiors, from traditional homes to contemporary spaces. Mounted on a strong and durable base, this 50mm Glass Ball Mortice Knob is not only visually appealing but also built to withstand regular use, making it a practical choice for daily living. Its simple yet elegant design adds a sophisticated finishing touch to any door, enhancing both style and functionality.
Ideal for use with mortice locks and latches, this 50mm Glass Ball Mortice Knob delivers smooth operation and long-lasting reliability. Installation is straightforward, making it suitable for both DIY projects and professional fitting. Whether you are replacing older fittings or upgrading to a more stylish option, this plain 50mm Glass Ball Mortice Knob is a cost-effective solution that offers durability as well as a touch of understated luxury. Perfect for bedrooms, living areas, or office doors, it blends strength with simplicity, ensuring your hardware is both functional and attractive.
